Specification |
Model |
BS-500W-12V |
BS-500W-13.5V |
BS-500W-24V |
BS-500W-48V |
DC output |
12V 40A |
13.5V 36 A |
24V 20 A |
48V 10A |
Wave and noise |
100mVP-P |
100mVP-P |
100mVP-P |
100mVP-P |
Inlet stability |
±0.5% |
±0.5% |
±0.5% |
±0.5% |
Load stability |
±0.5% |
±0.5% |
±0.5% |
±0.5% |
Efficiency |
84% |
84% |
85.5% |
87% |
Adiustable range for DC voltage |
±10% |
±10% |
±10% |
±10% |
AC input voltage range |
170~264VAC 47~63Hz, 250~370VDC |
AC Inrush current |
Cold-start current 30A/230V |
OverLoad protection |
105%~201% hiccup mode ,auto-recovery |
Over-voltage protection |
|
Setup,rise,hold up time |
200ms, 50ms,20ms |
Withstand voltage |
I/P-O/P:1.5KvAC I/P-FG:1.5KvAC O/P-FG:0.5Kv AC 一分钟 |
Isolation resistance |
I/P-O/P I/P-FG O/P-FG:500VDC/100MΩ |
Working temperature |
-10℃~+50℃ |
Safety standards |
Design refer to GB4943,UL60950,EN60950 |
EMC standards |
Design refer to GB9254,EN55022 class B |
Weight |
1.8kg | |
