| Specification |
Model |
| Q-60B |
| CH1 |
CH2 |
CH3 |
CH4 |
| DC output |
5V 5.5A |
12V 2A |
-5V 0.5A |
-12V 0.5A |
| Wave and noise |
100mVP-P |
120mVP-P |
120mVP-P |
100mVP-P |
| Inlet stability |
±0.5% |
±1% |
±0.5% |
±0.5% |
| Load stability |
±0.5% |
±4.0% |
±1.0% |
±1.0% |
| DC output power |
60W |
| Efficiency |
70% |
| Adiustable range for DC voltage |
CH1:4.75~5.5V |
| AC input voltage range |
85~264VAC 120~370VDC |
| AC Inrush current |
Cold-start current 15A/115V 30A/230V |
| OverLoad protection |
105%～150% hiccup mode ,auto-recovery 105%~150% rated output power |
| Over-voltage protection |
CH1:5.75～6.75VDC |
| Setup,rise,hold up time |
1.6s, 20ms 12ms/115VAC 800ms, 20ms,60ms/230VAC |
| Withstand voltage |
I/P-O/P：3KvAC I/P-FG:1.5KvAC O/P-FG:0.5Kv AC 1 minute |
| Isolation resistance |
I/P-O/P I/P-FG O/P-FG:500VDC/100MΩ |
| Working temperature |
-10℃~+60℃ |
| Safety standards |
Design refer to GB4943,UL60950,EN60950 |
| EMC standards |
Design refer to GB9254,EN55022 classA |
| Weight |
0.56kg | |
