| Specification |
Model |
| B T-25A |
| 主回路 |
次回路 |
次回路 |
| DC output |
5V 2A |
12V 1A |
-5V 0.5A |
| Wave and noise |
50mV |
80mV |
50mV |
| Inlet stability |
±0.5% |
±1% |
±1% |
| Load stability |
±0.5% |
±1% |
±1% |
| Efficiency |
68% |
| Adiustable range for DC voltage |
10% |
| AC input voltage range |
176~264VAC 47~63Hz 255~370VDC |
| AC Inrush current |
Cold-start current 30A/230V |
| OverLoad protection |
105%～150% hiccup mode ,auto-recovery |
| Over-voltage protection |
|
| Setup,rise,hold up time |
200ms, 50ms,20ms |
| Withstand voltage |
I/P-O/P：1.5KvAC I/P-FG:1.5KvAC O/P-FG:0.5Kv AC 1 minute |
| Isolation resistance |
I/P-O/P I/P-FG O/P-FG :500VDC/100MΩ |
| Working temperature |
-10℃~+50℃ |
| Safety standards |
Design refer to GB4943,UL60950,EN60950 |
| EMC standards |
Design refer to GB9254,EN55022 classB |
| Weight |
0.30kg | |
