| Specification |
Model |
| BSP-100-5 |
BSP-100-12 |
BSP-100-24 |
BSP-100-48 |
| DC output |
5V 20A |
12V 8.5A |
24V 4.2A |
48V 2.1A |
| Wave and noise |
50mVP-P |
75mVP-P |
75mVP-P |
75mVP-P |
| Inlet stability |
±0.5% |
±0.5% |
±0.5% |
±0.5% |
| Load stability |
±1.0% |
±0.5% |
±0.5% |
±0.5% |
| Efficiency |
76% |
80% |
84% |
82% |
| Adiustable range for DC voltage |
±10% |
±10% |
±10% |
±10% |
| AC input voltage range |
85～264VAC 47-63Hz 120～370VDC |
| AC Inrush current |
Cold-start current 30A/230V |
| OverLoad protection |
105%～150% hiccup mode ,auto-recovery |
| Over-voltage protection |
|
| Setup,rise,hold up time |
600ms, 30ms, 20ms230VAC at full load |
| Withstand voltage |
I/P-O/P：3KvAC I/P-FG:1.5Kv O/P-FG:0.5Kv 1 minute |
| Isolation resistance |
I/P-O/P I/P-FG O/P-FG:500VDC/100MΩ |
| Working temperature |
-10℃～+50℃ |
| Safety standards |
Design refer to GB4943,UL60950,EN60950 |
| EMC standards |
Design refer to GB9254,EN55022 classB |
| Weight |
0.66kg |
