| Specification |
Model |
| SP-500-12 |
SP-500-15 |
SP-500-24 |
SP-500-48 |
| DC output |
12V 40A |
15V 33A |
24V 20A |
48V 10A |
| Wave and noise |
100mVP-P |
100mVP-P |
150mVP-P |
150mVP-P |
| Inlet stability |
±0.5% |
±0.5% |
±0.5% |
±0.5% |
| Load stability |
±1.0% |
±0.5% |
±0.5% |
±0.5% |
| Efficiency |
79% |
86% |
87% |
89% |
| Adiustable range for DC voltage |
±10% |
±10% |
±10% |
±10% |
| AC input voltage range |
88～264VAC 47-63Hz 120～370VDC |
| AC Inrush current |
Cold-start current 20A/115AC 40A/230V |
| OverLoad protection |
105%～150% hiccup mode ,auto-recovery |
| Over-voltage protection |
|
| Setup,rise,hold up time |
800ms, 50ms, 16ms/230VAC 2500ms 50ms 16ms/115VAC |
| Withstand voltage |
I/P-O/P：3KvAC I/P-FG:1.5Kv O/P-FG:0.5Kv 1 minute |
| Isolation resistance |
I/P-O/P I/P-FG O/P-FG:500VDC/100MΩ |
| Working temperature |
~-10℃----+60℃ |
| Safety standards |
Design refer to GB4943,UL60950,EN60950 |
| EMC standards |
Design refer toGB9254,EN55022 classB |
| Weight |
2kg |
