| Specification |
Model |
| BDR-60W-5 |
BDR-60W-12 |
BDR-60W-15 |
BDR-60W-24 |
| DC output |
5V 6.5A |
12V 4.5A |
15V 4A |
24V 2.5A |
| Wave and noise |
50MVP-P |
50MVP-P |
50MVP-P |
50MVP-P |
| Inlet stability |
±0.5% |
±0.5% |
±0.5% |
±0.5% |
| Load stability |
±1% |
±0.5% |
±0.5% |
±0.5% |
| Efficiency |
76% |
82% |
83% |
84% |
| Adiustable range for DC voltage |
±10% |
±10% |
±10% |
±10% |
| AC input voltage range |
88～264VAC/ 47～63Hz 124～370VDC |
| AC Inrush current |
Cold-start current 18A/115V 36A/230V |
| OverLoad protection |
105%～160% hiccup mode ,auto-recovery |
| Over-voltage protection |
115%～135%rated output voltage |
| Setup,rise,hold up time |
100ms, 30ms, 60ms /230VAC at full load |
| Withstand voltage |
I/P-O/P：3KvAC I/P-FG:1.5Kv O/P-FG:0.5Kv 1 minute |
| Isolation resistance |
I/P-O/P I/P-FG O/P-FG:500VDC/100MΩ |
| Working temperature |
~-10℃～+50℃ |
| Safety standards |
Design refer to GB4943,UL60950,EN60950 |
| EMC standards |
Design refer to GB9254,EN55022 classB |
| Weight |
0.3kg |
