| Specification |
Model |
|
BSR-25-12 |
BSR-25-15 |
BSR-25-24 |
BSR-25-48 |
| DC output |
12V 2A |
15V 1.7A |
24V 1A |
48V 0.5A |
| Wave and noise |
75MVP-P |
70MVP-P |
60MVP-P |
60MVP-P |
| Inlet stability |
±0.5% |
±0.5% |
±0.5% |
±0.5% |
| Load stability |
±1% |
±0.5% |
±0.5% |
±0.5% |
| Efficiency |
76% |
77% |
80% |
82% |
| Adiustable range for DC voltage |
±10% |
±10% |
±10% |
±10% |
| AC input voltage range |
85～264VAC/47～63Hz 120～370VDC |
| AC Inrush current |
Cold-start current 15A/115V 30A/230V
|
| OverLoad protection |
105%～201% hiccup mode ,auto-recovery |
| Over-voltage protection |
115%～135%rated output voltage |
| Setup,rise,hold up time |
300ms, 50ms, 80ms/230VAC |
| Withstand voltage |
I/P-O/P：3KvAC I/P-FG:1.5Kv O/P-FG:0.5Kv 1 minute |
| Isolation resistance |
I/P-O/P I/P-FG O/P-FG:500VDC/100MΩ |
| Working temperature |
-10℃～+50℃ |
| Safety standards |
Design refer to GB4943,UL60950,EN60950 |
| EMC standards |
Design refer to GB9254,EN55022 classB |
| Weight |
0.20kg | |
