| Specification |
Model |
| S-100-5FYA |
S-100-12FYA |
S-100-24FYA |
S-100-48FYA |
| DC output |
5V 20A |
12V 8.5 A |
24V 4.5A |
48V 2A |
| Wave and noise |
75mVP-P |
50mVP-P |
50mVP-P |
50mVP-P |
| Inlet stability |
±0.5% |
±0.3% |
±0.2% |
±0.2% |
| Load stability |
±0.5% |
±0.3% |
±0.2% |
±0.2% |
| Efficiency |
78% |
81% |
84% |
84% |
| Adiustable range for DC voltage |
±10% |
±10% |
±10% |
±10% |
| AC input voltage range |
170~264VAC Selected by switch 47~63Hz, |
| AC Inrush current |
Cold-start current 30A/115V 60A/230V |
| OverLoad protection |
105%～150% hiccup auto-shut off AC recycle to restart |
| Over-voltage protection |
|
| Setup,rise,hold up time |
200ms, 50ms,20ms |
| Withstand voltage |
I/P-O/P：1.5KvAC I/P-FG:1.5KvAC O/P-FG:0.5Kv AC 1minute |
| Isolation resistance |
I/P-O/P I/P-FG O/P-FG:500VDC/100MΩ |
| Working temperature |
-10℃~+50℃ |
| Safety standards |
Design refer to GB4943,UL60950,EN60950 |
| EMC standards |
Design refer to GB9254,EN55022 classA |
| Weight |
0.5kg | |
