| Specofication |
Model |
| BBS-20-5 |
BBS-20-12 |
BBS-20-15 |
BBS-20-24 |
| DC output |
5V 4A |
12V 1.7A |
15V 1.3A |
24V 0.85A |
| Wave and noise |
80mVp-p |
80mVp-p |
100mVp-p |
100mVp-p |
| Inlet stability |
±0.5% |
±0.5% |
±0.5% |
±0.5% |
| Load stability |
±0.5% |
±0.5% |
±0.5% |
±0.5% |
| Efficiency |
68% |
71% |
72% |
75% |
| Adjustable range for DC voltage |
±10% |
±10% |
±10% |
±10% |
| AC input voltage range |
100-240VAC 47--63HZ |
| AC inrush current |
Cold-start current 30A/230V |
| OverLoad protection |
105%--135% hiccup mode,auto-recovery |
| Over-voltage protection |
|
| Setup,rise,hold up time |
200ms 50ms 20ms |
| Withstand voltage |
I/P-O/P：1.5KvAC I/P-FG：1.5Kv O/P-FG：0.5Kv 1minute |
| Isolation resistance |
I/P-O/P I/P-FG O/P-FG:500VDC/100MΩ |
| Working temperature |
~-10℃----+50℃ |
| Safety standards |
Design refer to GB4943，UL60950，EN60950 |
| EMC standards |
Design refer to GB9254，EN55022 Class B |
| Weight |
0.15kg |
