| Specification |
Model |
| BSP-15-5 |
BSP-15-12 |
BSP-15-15 |
BSP-10-24 |
| DC output |
5V 3A |
12V 1.3 A |
15V 1A |
24V 0.7A |
| Wave and noise |
50mVP-P |
50mVP-P |
75mVP-P |
100mVP-P |
| Inlet stability |
±0.5% |
±0.5% |
±0.5% |
±0.5% |
| Load stability |
±1% |
±0.5% |
±0.5% |
±0.5% |
| Efficiency |
65% |
68% |
70% |
72% |
| Adiustable range for DC voltage |
±10% |
±10% |
±10% |
±10% |
| AC input voltage range |
85～132VAC/170~264VAC Selected by switch 47~63Hz，240~370VDC |
| AC Inrush current |
Cold-start current 15A/115 30A/230V |
| OverLoad protection |
105%～150%hiccup mode ,auto-recovery |
| Over-voltage protection |
|
| Setup,rise,hold up time |
200ms, 100ms, 30ms |
| Withstand voltage |
I/P-O/P：1.5KvAC1 minute |
| Isolation resistance |
I/P-O/P :500VDC/100MΩ |
| Working temperature |
-10℃~+50℃ |
| Safety standards |
Design refer to GB4943,UL60950,EN60950 |
| EMC standards |
Design refer to GB9254,EN55022 classA |
| Weight |
0.12kg | |
