| Specification |
Model |
| BSP-10-5 |
BSP-10-12 |
BSP-10-24 |
| DC output |
5V 2A |
12V 0.8 A |
24V 0.4A |
| Wave and noise |
|
50mVP-P |
75mVP-P |
| Inlet stability |
±0.5% |
±0.5% |
±0.5% |
| Load stability |
|
±0.5% |
±0.5% |
| Efficiency |
77% |
80% |
84% |
| Adiustable range for DC voltage |
|
±10% |
±10% |
| AC input voltage range |
85～264VAC 47~63Hz 120～370VDC |
| AC Inrush current |
Cold-start current 30A/230V |
| OverLoad protection |
105%～135%hiccup mode ,auto-recovery |
| Over-voltage protection |
|
| Setup,rise,hold up time |
200ms, 50ms, 20ms |
| Withstand voltage |
I/P-O/P：1.5KvAC1 minute |
| Isolation resistance |
I/P-O/P :500VDC/100MΩ |
| Working temperature |
-10℃~+50℃ |
| Safety standards |
Design refer to GB4943,UL60950,EN60950 |
| EMC standards |
Design refer to GB9254,EN55022 classB |
| Weight |
0.14kg | |
