| Specofication |
Model |
| BRS-15-5 |
BRS-15-12 |
BRS-15-24 |
BRS-15-48 |
| DC output |
5V 3A |
12V 1.3A |
24V 0.625A |
48V 0.313A |
| Wave and noise |
80mVp-p |
120mVp-p |
120mVp-p |
120mVp-p |
| Inlet stability |
±0.5% |
±0.5% |
±0.5% |
±0.5% |
| Load stability |
±0.5% |
±0.5% |
±0.5% |
±0.5% |
| Efficiency |
77% |
81% |
82% |
82% |
| Adjustable range for DC voltage |
±10% |
±10% |
±10% |
±10% |
| AC input voltage range |
88-264VAC 47--63HZ |
| AC inrush current |
Cold-start current 50A/230V |
| OverLoad protection |
＞105% hiccup mode,auto-recovery |
| Over-voltage protection |
115%--135%,shut off |
| Setup,rise,hold up time |
1000ms 30ms 70ms/230VAC; 1000ms 30ms 15ms/230VAC |
| Withstand voltage |
I/P-O/P：1.5KvAC I/P-FG：1.5Kv O/P-FG：0.5Kv 1minute |
| Isolation resistance |
I/P-O/P I/P-FG O/P-FG:500VDC/100MΩ |
| Working temperature |
~-10℃----+50℃ |
| Safety standards |
Design refer to GB4943，UL60950，EN60950 |
| EMC standards |
Design refer to GB9254，EN55022 Class B |
| Weight |
0.15kg |
