| Specofication |
Model |
| BNES-400-12 |
BNES-400-15 |
BNES-400-24 |
BNES-400-48 |
| DC output |
12V 33A |
15V 26A |
24V 17A |
48V 8.5A |
| Wave and noise |
80mVp-p |
120mVp-p |
120mVp-p |
120mVp-p |
| Inlet stability |
±0.5% |
±0.5% |
±0.5% |
±0.5% |
| Load stability |
±0.5% |
±0.5% |
±0.5% |
±0.5% |
| Efficiency |
78% |
83% |
86% |
87% |
| Adjustable range for DC voltage |
±10% |
±10% |
±10% |
±10% |
| AC input voltage range |
AC110/220± 20% 47--63HZ |
| AC inrush current |
Cold-start current 50A/230V |
| OverLoad protection |
110%--150% hiccup mode,auto-recovery |
| Over-voltage protection |
|
| Setup,rise,hold up time |
800ms 20ms 24ms/230VAC; 1200ms 30ms 20ms/115VAC |
| Withstand voltage |
I/P-O/P：1.5KvAC I/P-FG：1.5Kv O/P-FG：0.5Kv 1minute |
| Isolation resistance |
I/P-O/P I/P-FG O/P-FG:500VDC/100MΩ |
| Working temperature |
~-10℃----+50℃ |
| Safety standards |
Design refer to GB4943，UL60950，EN60950 |
| EMC standards |
Design refer to GB9254，EN55022 Class B |
| Weight |
0.9kg |
