| Specification |
Model |
| BSD- 200B-5 |
BSD- 200C-5 |
BSD- 200D-5 |
BSD- 200B-12 |
BSD- 200C-12 |
BSD- 200D-12 |
BSD- 200B-24 |
BSD- 200C-24 |
BSD- 200D-24 |
| DC OUTPUT |
5V 34A |
12V 16.7A |
24V 8.4A |
| Wave and noise |
100mV |
120mV |
150mV |
| Line regulation |
±0.5% |
±0.3% |
±0.2% |
| Load regulation |
±0.5% |
±0.3% |
±0.2% |
| Voltage tolerance |
±2% |
±1% |
±1% |
| DC adjustment range |
4.75-5.5VDC |
10.8-13.2VDC |
21.6-26.4VDC |
| Efficiency |
79% |
81% |
82% |
82% |
84% |
82% |
85% |
86% |
84% |
| DC input voltage range |
B:19-36VDC C:36-72VDC D:72-144VDC |
| OverLoad protection |
105%--135% hiccup mode ,auto-recovery |
| Over-voltage protection |
110%--167% rated output voltage |
| Setup,Rise,Hold up time |
300ms,50ms, (at full load) |
| Withstand voltage |
I/P-O/P：1.5KvAC I/P-FG：1.5Kv O/P-FG：0.5Kv 1 minute |
| Isolation resistance |
I/P-O/P I/P-FG O/P-FG :500VDC/100MΩ |
| Working temperature |
-10℃ to 60℃ |
| Safety standards |
Design refer to GB4943，UL60950，EN60950 |
| EMC standards |
Design refer to GB9254，EN55022 class B |
| Weight |
1.1kg |
