| Specification |
Model |
| BSD- 50A-5 |
BSD-50B-5 |
BSD- 50C-5 |
BSD- 50A-12 |
BSD- 50B-12 |
BSD- 50C-12 |
BSD- 50A-24 |
BSD- 50B-24 |
BSD- 50C-24 |
| DC OUTPUT |
5V 10A |
12V 4.2A |
24V 2.1A |
| Wave and noise |
100mV |
120mV |
150mV |
| Line regulation |
±0.5% |
±0.3% |
±0.2% |
| Load regulation |
±0.5% |
±0.3% |
±0.2% |
| Voltage tolerance |
±2% |
±1% |
±1% |
| DC adjustment range |
4.75-5.5VDC |
10.8-13.2VDC |
21.6-26.4VDC |
| Efficiency |
70% |
73% |
76% |
72% |
78% |
80% |
74% |
80% |
83% |
| DC input voltage range |
A: 9.2-18VDC B:19-36VDC C:36-72VDC |
| OverLoad protection |
105%--150% hiccup mode ,auto-recovery |
| Over-voltage protection |
115%--165% rated output voltage |
| Setup,Rise,Hold up time |
2.5s,50ms, (at full load) |
| Withstand voltage |
I/P-O/P：1.5KvAC I/P-FG ：1.5Kv O/P-FG：0.5Kv 1 minute |
| Isolation resistance |
I/P-O/P I/P-FG O/P-FG :500VDC/100MΩ |
| Working temperature |
-10℃ to 60℃ |
| Safety standards |
Design refer to GB4943，UL60950，EN60950 |
| EMC standards |
Design refer to GB9254，EN55022 class B |
| Weight |
0.48kg |
