| Specification |
Model |
| BSD- 15A-5 |
BSD- 15B-5 |
BSD- 15C-5 |
BSD- 15A-12 |
BSD- 15B-12 |
BSD- 15C-12 |
BSD- 15A-24 |
BSD- 15B-24 |
BSD- 15C-24 |
| DC output |
5V 3A |
12V 1.25A |
24V 0.625A |
| Wave and noise |
100mV |
120mV |
150mV |
| Line regulation |
±0.5% |
±0.3% |
±0.2% |
| Load regulation |
±0.5% |
±0.3% |
±0.2% |
| Voltage tolerance |
±2% |
±1% |
±1% |
| DC adjustment range |
4.75-5.5VDC |
10.8-13.2VDC |
21.6-26.4VDC |
| Efficiency |
68% |
76% |
75% |
72% |
76% |
79% |
70% |
77% |
78% |
| DC input voltage range |
A: 9.2-18VDC B:19-36VDC C:36-72VDC |
| OverLoad protection |
105%--160% hiccup mode ,auto-recovery |
| Over-voltage protection |
115%--135% rated output voltage |
| Setup,Rise,Hold up time |
2.5s,25ms,---12VDC 24VDC 48VDC (at full load) |
| Withstand voltage |
I/P-O/P：1.5KvAC I/P-FG：1.5Kv O/P-FG：0.5Kv 1 minute |
| Working temperature |
0℃-40℃@100% -10℃@80% 60℃@60% load |
| Safety standards |
Design refer to GB4943，UL60950，EN60950 |
| EMC standards |
Design refer to GB9254，EN55022 class B |
| Weight |
0.18kg |
