| Specification |
Model |
| B S-35-5 |
B S-35-12 |
B S-35-15 |
B S-35-24 |
| DC output |
5V 7A |
12V 3A |
15V 2.4A |
24V 1.5A |
| Wave and noise |
50mVP-P |
50mVP-P |
50mVP-P |
75mVP-P |
| Inlet stability |
±1% |
±0.5% |
±0.5% |
±0.5% |
| Load stability |
±1% |
±0.5% |
±0.5% |
±0.5% |
| Efficiency |
77% |
81% |
83% |
84% |
| Adiustable range for DC voltage |
±10% |
±10% |
±10% |
±10% |
| AC input voltage range |
85～264VAC 47~63Hz, 120~370VDC |
| AC Inrush current |
Cold-start current 40A/230V |
| OverLoad protection |
105%～150% hiccup mode ,auto-recovery |
| Over-voltage protection |
115%~135% rated output voltage |
| Setup,rise,hold up time |
300ms, 50ms, 80ms |
| Withstand voltage |
I/P-O/P：1.5KvAC I/P-FG:1.5KvAC O/P-FG:0.5Kv AC 1 minute |
| Isolation resistance |
I/P-O/P I/P-FG O/P-FG:500VDC/100MΩ |
| Working temperature |
-10℃~+50℃ |
| Safety standards |
Design refer to GB4943,UL60950,EN60950 |
| EMC standards |
Design refer to GB9254,EN55022 classB |
| Weight |
0.29kg | |
