| Specification |
Model |
| B S-15-5 |
B S-15-12 |
B S-15-15 |
B S-15-24 |
| DC output |
5V 3A |
12V 1.3A |
15V 1A |
24V 0.7A |
| Wave and noise |
60mVP-P |
80mVP-P |
100mVP-P |
100mVP-P |
| Inlet stability |
±0.5% |
±0.5% |
±0.5% |
±0.5% |
| Load stability |
±0.5% |
±0.5% |
±0.5% |
±0.5% |
| Efficiency |
68% |
71% |
72% |
75% |
| Adiustable range for DC voltage |
±10% |
±10% |
±10% |
±10% |
| AC input voltage range |
85～264VAC 47-63Hz，120~370VDC |
| AC Inrush current |
Cold-start current 30A/230V |
| OverLoad protection |
105%～135% hiccup mode ,auto-recovery |
| Over-voltage protection |
|
| Setup,rise,hold up time |
200ms, 50ms, 20ms |
| Withstand voltage |
I/P-O/P：1.5KvAC I/P-FG:1.5KvAC O/P-FG:0.5Kv AC 1 minute |
| Isolation resistance |
I/P-O/P I/P-FG O/P-FG
:500VDC/100MΩ |
| Working temperature |
~-10℃~+50℃ |
| Safety standards |
Design refer to GB4943,UL60950,EN60950 |
| EMC standards |
Design refer to GB9254,EN55022 classB |
| Weight |
0.15kg | |
