Specification
|
Model |
| S-35-5 |
S-35-12 |
S-35-15 |
S-35-24 |
| DC output |
5V 7A |
12V 3A |
15V 2.4A |
24V 1.5A |
| Wave and noise |
50mVP-P |
50mVP-P |
50mVP-P |
75mVP-P |
| Inlet stability |
±0.5% |
±0.5% |
±0.5% |
±0.5% |
| Load stability |
±1% |
±0.5% |
±0.5% |
±0.5% |
| Efficiency |
70% |
76% |
78% |
78% |
| Adjustable range for DC voltage |
±10% |
±10% |
±10% |
±10% |
| AC input voltage range |
85～132VAC/170~264VAC Selected by switch 47~63Hz, 240~370VDC |
| AC Inrush current |
Cold-start current 18A/115V 36A/230V |
| OverLoad protection |
105%～150% hiccup mode, auto-recovery |
| Over-voltage protection |
|
| Setup, rise, hold up time |
200ms, 100ms, 30ms |
| Withstand voltage |
I/P-O/P：1.5KvAC I/P-FG:0.5KvAC O/P-FG::0.5Kv AC 1minute |
| Isolation resistance |
I/P-O/P,I/P-FG,O/P-FG:500VDC/100MΩ |
| Working temperature |
-10℃~+50℃ |
| Safety standards |
Design refer to GB4943,UL60950,EN60950 |
| EMC standards |
Design refer to GB9254,EN55022 classA |
| Weight |
0.4kg | |
