| Specification |
Model |
| B S-800-24 |
B S-800-36 |
B S-800-48 |
| DC output |
24V 33A |
36V 22A |
48V 17A |
| Wave and noise |
100mVP-P |
100mVP-P |
150mVP-P |
| Inlet stability |
±0.5% |
±0.5% |
±0.5% |
| Load stability |
±0.5% |
±0.5% |
±0.5% |
| Efficiency |
85% |
85% |
87% |
| Adiustable range for DC voltage |
±10% |
±10% |
±10% |
| AC input voltage range |
176~264VAC 47~63Hz 255~370VDC |
| AC Inrush current |
Cold-start current 45A/230V |
| OverLoad protection |
105%～135% hiccup mode ,auto-recovery |
| Over-voltage protection |
115%~140% rated output voltage |
| Setup,rise,hold up time |
2000ms, 50ms,20ms |
| Withstand voltage |
I/P-O/P：1.5KvAC I/P-FG:1.5KvAC O/P-FG:0.5Kv AC 1 minute |
| Isolation resistance |
I/P-O/P I/P-FG O/P-FG:500VDC/100MΩ |
| Working temperature |
-10℃~+50℃ |
| Safety standards |
Design refer to GB4943,UL60950,EN60950 |
| EMC standards |
Design refer to GB9254,EN55022 classB |
| Weight |
3.7kg | |
