| Specification |
Model |
| BSE-600E-5 |
BSE-600E-12 |
BSE-600E-24 |
BSE-600E-48 |
| DC output |
5V 100A |
12V 50A |
24V 25A |
48V 12.5A |
| Wave and noise |
100mVP-P |
75mVP-P |
75mVP-P |
75mVP-P |
| Inlet stability |
±0.5% |
±0.5% |
±0.5% |
±0.5% |
| Load stability |
±1% |
±0.5% |
±0.5% |
±0.5% |
| Efficiency |
78% |
83% |
87% |
88% |
| Adiustable range for DC voltage |
±10% |
±10% |
±10% |
±10% |
| AC input voltage range |
AC110/220V±20% selectble by switch |
| AC Inrush current |
Cold-start current 30A/115V 50A/230V |
| OverLoad protection |
105%～150% hiccup mode ,auto-recovery |
| Over-voltage protection |
120%~140% rated output voltage |
| Setup,rise,hold up time |
1000ms, 50ms,16ms at full load and 230VAC |
| Withstand voltage |
I/P-O/P：3KvAC I/P-FG:1.5KvAC O/P-FG:0.5Kv AC 1 minute |
| Isolation resistance |
I/P-O/P I/P-FG O/P-FG:500VDC/100MΩ |
| Working temperature |
-10℃~+50℃ |
| Safety standards |
Design refer to GB4943,UL60950,EN60950 |
| EMC standards |
Design refer to GB9254,EN55022 classB |
| Weight |
2.1kg |
