Specification
|
Model |
| S-25-5 |
S-25-12 |
S-25-15 |
S-25-24 |
| DC output |
5V 5A |
12V 2.1A |
15V 1.7A |
24V 1.1A |
| Wave and noise |
50mVP-P |
50mVP-P |
75mVP-P |
75mVP-P |
| Lnlet stability |
±0.5% |
±0.5% |
±0.5% |
±0.5% |
| Load stability |
±1% |
±0.5% |
±0.5% |
±0.5% |
| Efficiency |
72% |
76% |
77% |
80% |
| Adijustable range for DC voltage |
±10% |
±10% |
±10% |
±10% |
| AC input voltage range |
85～264VAC 47~63Hz, 120~370VDC |
| AC lnrush current |
Cold-start current 15A/115V 30A/230V |
| Over Load protection |
105%～150% hiccup mode, auto-recovery |
| Over-voltage protection |
115%~135% rated output voltage |
| Setup,rise, hold up time |
at full load and 230VAC |
| Withstand voltage |
I/P-O/P：1.5KvAC I/P-FG:1.5KvAC O/P-FG:0.5Kv AC 1minute |
| lsolation resistance |
I/P-O/P, I/P-FG, O/P-FG:500VDC/100MΩ |
| Working temperature |
-10℃~+50℃ |
| Safety standards |
Design refer to GB4943,UL60950,EN60950 |
| EMC standards |
Design refer to GB9254,EN55022 classB |
| Weight |
0.39kg |
