| Specification |
Model |
| S-240-5 |
S-240-12 |
S-240-24 |
S-240-48 |
| DC output |
5V 40A |
12V 18 A |
24V 10A |
48V 5A |
| Wave and noise |
100mVP-P |
75mVP-P |
75mVP-P |
75mVP-P |
| Inlet stability |
±2% |
±1% |
±1% |
±1% |
| Load stability |
±2% |
±1% |
±1% |
±1% |
| Efficiency |
78% |
82% |
84% |
87% |
| Adiustable range for DC voltage |
±10% |
±10% |
±10% |
±10% |
| AC input voltage range |
85～132VAC/170~264VAC Selected by switch 47~63Hz, 240~370VDC |
| AC Inrush current |
Cold-start current 18A/230V 36A/230V |
| OverLoad protection |
105%～135% hiccup mode ,auto-recovery |
| Over-voltage protection |
115%~150% rated output voltage |
| Setup,rise,hold up time |
100ms, 20ms,20ms/230VAC |
| Withstand voltage |
I/P-O/P：3KvAC I/P-FG:1.5KvAC O/P-FG:0.5Kv AC 1 minute |
| Isolation resistance |
I/P-O/P I/P-FG O/P-FG:500VDC/100MΩ |
| Working temperature |
-10℃~+50℃ |
| Safety standards |
Design refer to GB4943,UL60950,EN60950 |
| EMC standards |
Design refer to GB9254,EN55022 classB |
| Weight |
1.2kg | |
