| Specofication |
Model |
| S-50B-5 |
S-50B-12 |
S-50B-15 |
S-50B-24 |
| DC output |
5V 10A |
12V 4.2A |
15V 3.4A |
24V 2.1A |
| Wave and noise |
60mVp-p |
50mVp-p |
50mVp-p |
75mVp-p |
| Inlet stability |
±0.5% |
±0.5% |
±0.5% |
±0.5% |
| Load stability |
±1% |
±0.5% |
±0.5% |
±0.5% |
| Efficiency |
71% |
78% |
78% |
82% |
| Adjustable range for DC voltage |
±10% |
±10% |
±10% |
±10% |
| AC input voltage range |
85-132VAC/170-264VAC Selected by switch 47--63HZ 240-370VAC |
| AC inrush current |
Cold-start current 15A/115V 30A/230V |
| OverLoad protection |
105%--150 hiccup mode,auto-recovery |
| Over-voltage protection |
|
| Setup,rise,hold up time |
200ms 100ms 20ms |
| Withstand voltage |
I/P-O/P：1.5KvAC I/P-FG：1.5Kv O/P-FG：0.5Kv 1minute |
| Isolation resistance |
I/P-O/P I/P-FG O/P-FG:500VDC/100MΩ |
| Working temperature |
~-10℃----+50℃ |
| Safety standards |
Design refer to GB4943，UL60950，EN60950 |
| EMC standards |
Design refer to GB9254，EN55022 Class A |
| Weight |
0.5kg |
